Deye SUN-12K-G05-LV
Code: DEYE-SUN-12K-G05-LV
Product detailed description
Key Features
- High efficiency: with a maximum efficiency of 98.6%, this inverter minimizes energy loss and maximizes solar energy harvest.
- Versatile Use: Supports both zero export and VSG applications, allowing you to customize your energy management strategy.
- Intelligent Monitoring: Intelligent string monitoring (optional) provides real-time visibility into the performance of individual strings, facilitating efficient maintenance and troubleshooting.
- Wide voltage range: seamless operation with 127 V/220 V, 133 V/230 V and 50/60 Hz systems, ensuring compatibility with a wide range of solar equipment.
- Advanced protection: incorporates comprehensive protection measures including AC/DC over-voltage and under-voltage protection, short circuit protection and islanding protection, ensuring safe and reliable operation.
- User-friendly design: Compact and lightweight design with IP65 rating for weatherproofing, making installation and maintenance easy.
- Communication Options: Supports multiple communication options including GPRS/WIFI/Bluetooth/4G/LAN (optional) for seamless system monitoring and control.
Additional parameters
| Category: | Solar inverters |
|---|---|
| Weight: | 20 kg |
| Brand: | DEYE |
| Lenght: | 220 mm |
| Width: | 362 mm |
| Height: | 527 mm |
| Power: | 12000 W |
| Number of phases: | 3 |
| Degree of protection (IP): | IP65 |
| Communication: | RS485, Wi-Fi, LAN, 4G, Bluetooth, RS232, GPRS |
| Number of MPPT: | 2 |
| String: | 2+2 |
| Type: | Grid tie |
| Voltage converters - DEYE - Model series: | G05 | 3 Phase | 2 MPPT | Low Voltage |
| Nominal voltage: | 230 V, 133 V |
| Operating voltage: | 200 - 700 VDC |
| Maximum Output Power: | 12000 VA |
