Deye SUN-130K-G01P3

Product detailed description

Key Features

• Best efficiency: it achieves a maximum efficiency of up to 98.8% and a European efficiency of 98.2%, ensuring excellent energy conversion for optimum performance.
• Eight MPPT trackers: the MPPT (Maximum Power Point Tracking), which allows for precise power optimization under changing solar radiation conditions and ensures that each string of solar panels is operating at its maximum potential.
• Zero export and VSG applications: supports zero export applications to avoid feeding back excess generated power to the grid, and includes virtual synchronous generator (VSG) functions to enhance grid stability.
• Wide MPPT voltage range: Offers an MPPT voltage range from 200 V to 1,000 V, providing the flexibility to adapt to different PV string configurations and lengths for a variety of installation scenarios.
• Anti-PID feature (optional): Includes an optional anti-potential degradation (PID) feature that helps protect solar modules from power loss, extending their lifetime and maintaining higher power output.
• Advanced Protection Mechanisms: Equipped with Type II DC/AC surge protection devices (SPD) and comprehensive protection features such as reverse polarity protection, AC and surge protection, short circuit protection, and thermal protection.
• Flexible communication and monitoring: provides multiple monitoring options such as GPRS, WiFi, Bluetooth, 4G and LAN (optional), along with RS485 and RS232 communication interfaces for easy integration and real-time system monitoring.
• Rugged construction: these inverters are constructed with IP65 protection and designed to operate over a wide temperature range from -25°C to +60°C (with derating above 45°C) to withstand harsh environmental conditions. They operate efficiently up to an altitude of 4,000 meters and maintain noise levels below 65 dB.
• Conformance and certification: they comply with international safety and performance standards such as IEC 61727, IEC 62116, CEI 0-21, EN 50549, NRS 097, RD 140, UNE 217002, OVE-Richtlinie R25, G99 and VDE-AR-N 4105. Meets EMC standards including IEC/EN 61000-6-1/2/3/4 and IEC/EN 62109-1/2.
