    Solis S6-EH1P14K03-NV-YD-L

    Code: SOLIS-S6-EH1P14K03-NV-YD-L
    Not rated
    Solis S6-EH1P14K03-NV-YD-L
    €1 780,20 €2 189,65 incl. VAT
    On order

    The S6-EH1P(9.9–18)K03-NV-YD-L series energy storage inverter is designed for large residential PV systems, supporting up to 40A MPPT input current, making it fully compatible with high-power 182mm and 210mm solar panels. It includes integrated battery management and protection features, ensuring extended battery life and system safety.

    Detailed information

    Fair price
    Fair price
    We offer competitive prices with an emphasis on quality and transparency
    Fast delivery
    Fast delivery
    Products in stock, ships now. Backordered items ship in 5 days.
    Loyalty bonus
    Loyalty bonus
    Regular customers get discounts and bonuses for their loyalty.
    Expert turnkey installation
    Expert turnkey installation
    We provide end-to-end services with a quality guarantee.

    Product detailed description

    This inverter supports parallel operation, allowing multiple units to be combined into single-phase or three-phase configurations, with a total output capacity of up to 160kW. It also supports AC coupling, making it ideal for retrofitting existing PV systems.

    With a maximum charge/discharge current of 350A, it delivers high energy density and fast response times. Combining intelligent control and robust reliability, it is a top-tier solution for large-scale residential energy storage applications.

    Key Features:

    Smart Energy Management

    • Built-in control for SG-ready heat pumps
    • Seamless integration with VPP and EMS platforms for enhanced energy optimization
    • AI intelligently manages charging and discharging based on TOU (Time-of-Use) tariffs

    High Performance

    • Switching time < 4ms
    • 160% PV input capacity to maximize solar energy utilization

    Flexible & Scalable

    • Compatible with mainstream lithium and lead-acid batteries
    • Easily expand system capacity using parallel connections and AC coupling

    Simple & Fast Configuration

    • 7-inch LCD screen for an intuitive user experience
    • Bluetooth app support for quick and easy setup

    Additional parameters

    Category: Inverters
    Weight: 55.5 kg
    Brand: Solis
    Power: 14000 W
    Number of phases: 1
    Degree of protection (IP): IP66
    Number of MPPT: 3
    Communication: RS485, Wi-Fi, LAN, Cellular
    Nominal voltage: 230 V
    Lenght: 313 mm
    Width: 459 mm
    Height: 845 mm
    String: Up to 2 per MPPT
    Type: Hybrid
