    Home / Photovoltaics / Inverters / Solis S6-EH1P4.6K-L-PLUS

    Solis S6-EH1P4.6K-L-PLUS

    Code: SOLIS-S6-EH1P4.6K-L-PLUS
    Not rated
    Brand: Solis
    Solis S6-EH1P4.6K-L-PLUS
    €1 000 000 €1 230 000 incl. VAT
    On order

    The S6-EH1P(3–10)K-L-PLUS series energy storage inverter is designed for residential PV systems, offering robust performance and smart energy management. It supports up to 32A MPPT input current, making it compatible with a wide range of high-power PV modules.

    Detailed information

    Product detailed description

    With a 6-stage timed charge/discharge function and built-in battery care and protection features, it extends battery life and enhances system reliability. The inverter also supports parallel connection of multiple units, allowing configuration of single-phase or three-phase systems with up to 48kW of total power output.

    Equipped with UPS-level switching and a dedicated generator interface, it ensures stable and uninterrupted power supply, even during outages. This versatile inverter offers an ideal solution for homes needing reliable and intelligent energy storage in demanding power environments.

    Key Features

    Smart Energy Management
    • AI intelligently manages charging and discharging based on TOU (Time-of-Use) tariffs
    • Seamless integration with VPP and EMS platforms for enhanced energy optimization

    High Performance

    • Switching time < 4ms
    • 160% PV input capacity to maximize solar energy utilization

    Flexible & Scalable

    • Compatible with mainstream lithium and lead-acid batteries
    • Easily expand system capacity using parallel connections and AC coupling

    Simple & Fast Configuration

    • 7-inch LCD screen for an intuitive user experience
    • Bluetooth app support for quick and easy setup

    Additional parameters

    Category: Inverters
    Weight: 23 kg
    Brand: Solis
    Power: 4600 W
    Number of phases: 1
    Degree of protection (IP): IP66
    Number of MPPT: 2
    Communication: RS485, CAN, Wi-Fi, LAN, GPRS
    Maximum output current: 20 A
    Nominal voltage: 230 V
    Lenght: 253 mm
    Width: 335 mm
    Height: 560 mm
    String: 1 Per MPPT
    Type: Hybrid
