Deye SUN-100K-G03

Product detailed description

• Exceptional efficiency: the SUN-G03 offers a maximum efficiency of up to 98.8%, with European efficiency reaching up to 98.2%. This high efficiency ensures that more energy from the solar panels is converted into usable electricity, maximising return on investment by minimising losses.
• Multiple MPPT channels: equipped with up to 6 MPPT (Maximum Power Point Tracking) channels, these inverters optimize the output from multiple strings of solar panels, especially in installations with different orientations and shading conditions, and allow precise tracking of the optimal power point of each string.
• Wide MPPT voltage range: the inverters operate over a wide MPPT voltage range of 200-850 V, offering greater flexibility in system design and adapting to different solar panel configurations.
• The SUN-G03 series incorporates comprehensive protection mechanisms such as DC over-current protection, AC output over-current and over-voltage protection, AC output short-circuit protection, thermal protection, and ground fault current monitoring to enhance solar system safety and reliability.
• The optional Anti-PID (Potential-Induced Degradation) function maintains the performance of the solar panels over time, while the zero export function ensures compliance with grid export limits, making these inverters suitable for regions with strict grid regulations.
• Rugged construction: the SUN-G03 inverters are housed in an IP65-rated enclosure and are built to withstand harsh environmental conditions. Their intelligent air-cooling system ensures efficient temperature control, operating over a temperature range of -25°C to +60°C, with temperature reduction above 45°C.
• Comprehensive network compatibility: These inverters meet multiple international network regulations and safety standards including IEC 61727, IEC 62116, EN 50549 and VDE-AR-N 4105, ensuring compatibility and safe operation in different regions and network conditions.
• Versatile communication and monitoring capabilities:With support for a variety of communication interfaces such as GPRS, Wi-Fi, Bluetooth, 4G, LAN, RS485 and RS232, the SUN-G03 series enables flexible monitoring and control, allowing users to efficiently manage and optimize their solar systems.
• Lightweight and compact: Despite the high power output, the inverters are compact and relatively lightweight (approximately 81 kg) with dimensions of 824 × 516 × 312.7 mm, simplifying the installation process and integration into existing systems.
• Grid support and power quality: The virtual synchronous generator (VSG) function and excellent total harmonic distortion (THD) of less than 3% support grid stability and power quality, making these inverters an excellent choice for modern grid-connected solar systems.
