SolaX X3-NEO-10K-LV 10kW Hybrid LV 3-phase Inverter
Code: X3-NEO-10K-LV
In stock, ships within 24h
We keep products in stock and dispatch your order within 24 hours.
9 out of 10 customers return
As many as 9 out of 10 customers come back to us for their next project.
4.9★ rated by installers
Professional installers rate us an average of 4.9 out of 5 stars.
One partner for the whole project
A complete range from one partner – no juggling multiple suppliers.
Product detailed description
Overview
SolaX X3-NEO-10K-LV - 10 kW three-phase low-voltage hybrid inverter, 2 MPPT, 40-60 V battery, EPS backup, IP65.
Key Features
- 10 kW three-phase low-voltage hybrid inverter (X3-NEO-LV)
- 2 MPP trackers, MPPT 160-950 V, up to 20 kWp PV
- Low-voltage battery 40-60 V, high charge/discharge current
- EPS off-grid backup
- Max. efficiency 97.6%; IP65
Technical Specifications
| Rated AC output power | 10 kW |
| Max. AC apparent power | 11 kVA |
| Rated output current | 14.5 A @ 230 V |
| Phase | Three-phase (3W/N/PE), 230/400 V |
| Max. recommended PV power | 20 kWp |
| No. of MPP trackers | 2 (2+1) |
| Max. input current per MPPT | 36/18 A |
| Max. DC input voltage | 1000 V |
| MPPT voltage range | 160-950 V |
| Battery type / voltage | Low-voltage lithium, 40-60 V |
| Max. charge / discharge current | up to 280 A |
| Max. efficiency | 97.6% (Euro 97.0%) |
| Communication | RS485, CAN, USB, DI/DO |
| Protection rating | IP65 |
| Dimensions (W x H x D) | 520 x 705 x 258 mm |
| Weight | 44.6 kg |
Compatible Batteries
Works with SolaX Triple Power batteries. Always confirm the exact configuration with the supplier.
Additional parameters
| Category: | Solar inverters |
|---|---|
| Weight: | 44.6 kg |
| Brand: | SolaX |
| Power: | 10000 W |
| Number of phases: | 3 |
| Degree of protection (IP): | IP65 |
| Number of MPPT: | 2 |
| Inverters - Type: | Hybrid |
| Nominal voltage: | 400 V |
| Operating voltage: | 160-950 VDC |
| Maximum Output Power: | 11000 VA |
Product rating
Be the first who will post an article to this item!
Only registered users may submit ratings. Please log in or sign up.
Discussion
Be the first who will post an article to this item!
SolaX Power is a leading global manufacturer of solar inverters and energy storage systems for residential, commercial and industrial applications. Its range includes hybrid and on-grid inverters (X1, X3, X3-Ultra, X3-Forth), all-in-one IES systems, Triple Power batteries and C&I storage cabinets, all built around high-efficiency MPPT technology and smart monitoring.
| Manufacturing company : | SolaX Power Network Technology (Zhejiang) Co., Ltd. |
|---|---|
| Address : | No. 288 Shizhu Road, Tonglu Economic Development Zone, Tonglu, Hangzhou, Zhejiang, China |
| E-mail : | [email protected] |
