SolaX X3-Ultra-20K 20kW Hybrid HV 3-phase Inverter

Code: X3-ULTRA-20K

Not rated Rating details

Brand: SolaX Power

€0 €0 incl. VAT

SolaX X3-Ultra-20K - 20 kW three-phase HV hybrid (X3-Ultra), 3 , 120-800 V battery, EPS backup, IP66.

Detailed information

Fair price

We offer competitive prices with an emphasis on quality and transparency

Fast delivery

Products in stock, ships now. Backordered items ship in 5 days.

Loyalty bonus

Regular customers get discounts and bonuses for their loyalty.

Expert turnkey installation

We provide end-to-end services with a quality guarantee.

Product detailed description

Overview

SolaX X3-Ultra-20K - 20 kW three-phase HV hybrid inverter (X3-Ultra), 3 MPPT, 120-800 V battery, EPS backup, IP66.

Key Features

20 kW three-phase HV hybrid inverter (X3-Ultra), 3 MPP trackers
Up to 200% PV oversizing, 36 A per MPPT, 100% AC output
HV battery 120-800 V, 60 A charge/discharge
EPS off-grid backup; parallel up to 10 units
Max. efficiency 98.0%; IP66, smart air cooling

Technical Specifications

Rated AC output power	20 kW
Max. AC apparent power	22.0 kVA
Phase	Three-phase (3/N/PE), 230/400 V
No. of MPP trackers	3 (2+2+2)
Max. input current per MPPT	36 A
Max. DC input voltage	1000 V
Battery type / voltage	Lithium, 120-800 V (HV)
Max. charge / discharge current	60 A
EPS (off-grid) output	20 kVA, <10 ms switchover
Max. efficiency	98.0% (Euro 97.7%)
Communication	RS485, CAN, DRM, DI/DO; Pocket WiFi (opt.)
Protection rating	IP66
Dimensions (W x H x D)	696 x 526 x 240 mm
Weight	46 kg
Certifications	EN/IEC 62109-1/-2, VDE4105, G99, EN50549, RD1699

Compatible Batteries

Works with SolaX Triple Power batteries. Always confirm the exact configuration with the supplier.

Additional parameters

Category:	Solar inverters
Weight:	46 kg
Brand:	SolaX
Power:	20000 W
Number of phases:	3
Degree of protection (IP):	IP66
Number of MPPT:	3
Type:	Hybrid
Nominal voltage:	400 V
Maximum Output Power:	22000 VA

SolaX X3-Ultra Datasheet (PDF)
