Deye SUN-5K-SG03LP1-EU 5kW Hybrid LV 1-phase inverter
Code: SUN-5K-SG03LP1-EU
Related products
Product detailed description
Overview
The Deye SUN-5K-SG03LP1-EU is a 5kW single-phase hybrid inverter for 48 V low-voltage battery storage, ideal for homes and small businesses adding solar with energy storage. It supports AC coupling, backup power and flexible battery charge/discharge scheduling.
Key Features
- 5kW single-phase (230 V) hybrid inverter, 48 V low-voltage battery
- MPP tracking 2 / 1+1, MPPT range 150-425 V, max. PV input voltage 500 V
- Max. battery charge / discharge current 120 A
- AC coupling to retrofit existing PV; diesel-generator input supported
- 6 configurable charge/discharge time periods; parallel operation supported
- Max. efficiency 97.6%, IP65 for indoor and outdoor installation
Technical Specifications
| Rated AC output power | 5 000 W |
| Max. AC apparent power | 5500 VA |
| Phase | Single-phase (L+N+PE), 230 V |
| Max. PV input power | 6 500 W |
| Max. PV input voltage | 500 V |
| MPP trackers / strings | 2 / 1+1 |
| MPPT voltage range | 150-425 V |
| Battery type / voltage | Low-voltage Li-ion / lead-acid, 48 V |
| Rated / max AC current (in/out) | 22.8/21.8 A / 25/24 A |
| Max. charge / discharge current | 120 A |
| Max. efficiency | 97.6% (Euro 96.5%) |
| Communication | Wi-Fi / RS485 / CAN |
| Protection rating | IP65 |
| Operating temperature | -40 to +60 °C |
| Dimensions (W x H x D) | 330 x 580 x 232 mm |
| Weight | 20.5 kg |
| Warranty | 5 / 10 years |
Compatible Batteries
Works with 48 V low-voltage battery systems. Compatible with Deye LV battery lines (SE-F, RW-F) and a wide range of third-party LV batteries on Deye's official Approved Battery List (Pylontech, BSLBATT, Wattsonic and others). See the attached LV Battery Compatibility List; always confirm the exact model with the supplier.
Applications
- Residential and small commercial self-consumption with storage
- Backup power and off-grid operation
- Retrofit AC coupling of existing PV installations
Additional parameters
| Category: | Solar inverters |
|---|---|
| Weight: | 20.5 kg |
| Brand: | DEYE |
| Lenght: | 232 mm |
| Width: | 330 mm |
| Height: | 580 mm |
| Power: | 5000 W |
| Number of phases: | 1 |
| Degree of protection (IP): | IP65 |
| Communication: | RS485, CAN, Wi-Fi |
| Number of MPPT: | 2 |
| String: | 1 + 1 |
| Type: | Hybrid |
| Voltage converters - DEYE - Model series: | SG03LP1-EU | 1 Phase | 2 MPPT |
| Nominal voltage: | 230 V |
| Operating voltage: | 150-425 VDC |
| Maximum Output Power: | 5500 VA |
-
Deye SG03LP1-EU Hybrid Inverter Datasheet (PDF)
-
Deye SG03LP1-EU Hybrid Inverter User Manual (PDF)
-
Deye LV Battery Compatibility List (PDF)
