Deye SUN-XL02-B PV Module Optimizer (700 W)
Code: SUN-XL02-B
Related products
Product detailed description
Overview
The Deye SUN-XL02-B is part of the Deye SUN-XL optimizer system for residential and commercial PV. Module-level optimizers perform per-panel MPPT, increasing energy harvest under shading or panel mismatch and enabling module-level monitoring and rapid shutdown.
Key Features
- Module-level MPPT (per-panel) maximises array yield under shading/mismatch
- 700 W max input, MPPT range 12-80 V, 99.5% peak efficiency
- Per-module monitoring and module-level rapid shutdown
- PLC over existing PV cables - no extra communication wiring
- IP68, -40 to +85 °C; MC4 connectors
- Works with the SUN-XL20-B concentrator
Technical Specifications
| Maximum input power | 700 W |
| Maximum input voltage | 80 V |
| MPPT voltage range | 12-80 V |
| Maximum input current | 15 A |
| Peak conversion efficiency | 99.5% |
| Communication | PLC (power-line carrier) |
| Connector | MC4 or MC4-compatible |
| Cable | 4.0 mm², input 70 cm / output 100 cm |
| Protection rating | IP68 |
| Operating temperature | -40 to +85 °C |
| Dimensions (W x H x D) | 105 x 105 x 22 mm |
| Weight | 660 g |
System Compatibility
Use with the Deye SUN-XL20-B optimizer concentrator and Deye hybrid/string inverters for full monitoring. Always confirm the exact configuration with the supplier.
Additional parameters
| Category: | Optimisers |
|---|---|
| Weight: | 0.66 kg |
| Brand: | DEYE |
| Lenght: | 22 mm |
| Width: | 105 mm |
| Height: | 105 mm |
| Power: | 700 W |
| Degree of protection (IP): | IP68 |
| Communication: | PLC |
