Deye SUN-XL20-B Optimizer Concentrator
Code: SUN-XL20-B
Related products
Product detailed description
Overview
The Deye SUN-XL20-B is an optimizer concentrator (collector) for the Deye SUN-XL optimizer system. It collects performance data from the SUN-XL02 module-level optimizers over the existing PV cabling and relays it for monitoring.
Key Features
- Collects data from Deye SUN-XL02 module-level optimizers
- Up to 4 connected PV strings, max input current 20 A
- PLC over existing PV cables - no extra communication wiring
- System voltage up to 1500 V; powered DC 12-15 V from the inverter RSD
- IP68, -40 to +65 °C; MC4 connectors
- CE certified
Technical Specifications
| Number of connected strings | 4 |
| Maximum input current | 20 A |
| System voltage | 1000 V / 1500 V |
| Operating voltage | DC 12-15 V |
| Communication | PLC (power-line carrier) |
| Connector | MC4 or MC4-compatible |
| Protection rating | IP68 |
| Certification | CE |
| Operating temperature | -40 to +65 °C |
| Dimensions (W x H x D) | 229 x 109 x 38 mm |
| Weight | 1600 g |
System Compatibility
Use with Deye SUN-XL02-A / SUN-XL02-B module-level optimizers and Deye inverters. Always confirm the exact configuration with the supplier.
Additional parameters
| Category: | Optimisers |
|---|---|
| Weight: | 1.6 kg |
| Brand: | DEYE |
| Lenght: | 38 mm |
| Width: | 229 mm |
| Height: | 109 mm |
| Degree of protection (IP): | IP68 |
| Communication: | PLC |
