SolaX X3-FORTH-80K 80kW Commercial On-grid Inverter (3-phase)
Code: X3-FORTH-80K
In stock, ships within 24h
We keep products in stock and dispatch your order within 24 hours.
9 out of 10 customers return
As many as 9 out of 10 customers come back to us for their next project.
4.9★ rated by installers
Professional installers rate us an average of 4.9 out of 5 stars.
One partner for the whole project
A complete range from one partner – no juggling multiple suppliers.
Related products
Product detailed description
Overview
SolaX X3-FORTH-80K 80kW Commercial On-grid Inverter (3-phase) - on-grid (grid-tie) string inverter for solar PV without battery storage.
Key Features
- 80 kW three-phase commercial on-grid string inverter (X3-FORTH)
- 9 MPP trackers, 150% PV oversizing, 32 A/MPPT
- MPPT 180-1000 V, max PV 1100 V
- IP66, smart air cooling
Technical Specifications
| Rated AC apparent power | 80 kVA |
| Phase | Three-phase (3/N/PE), 230/400 V |
| Max. recommended PV power | 120 kWp |
| No. of MPP trackers | 9 |
| Max. PV input voltage | 1100 V |
| MPPT voltage range | 180-1000 V |
| Max. input current per MPPT | 32 A |
| Protection rating | IP66 |
| Cooling | Smart air cooling |
| Dimensions (W x H x D) | 985 x 660 x 327.5 mm |
| Weight | 83 kg |
Additional parameters
| Category: | Solar inverters |
|---|---|
| Weight: | 83 kg |
| Brand: | SolaX |
| Power: | 80000 W |
| Number of phases: | 3 |
| Degree of protection (IP): | IP66 |
| Number of MPPT: | 9 |
| Type: | Grid tie |
| Nominal voltage: | 400 V |
Product rating
Be the first who will post an article to this item!
Only registered users may submit ratings. Please log in or sign up.
Discussion
Be the first who will post an article to this item!
SolaX Power is a leading global manufacturer of solar inverters and energy storage systems for residential, commercial and industrial applications. Its range includes hybrid and on-grid inverters (X1, X3, X3-Ultra, X3-Forth), all-in-one IES systems, Triple Power batteries and C&I storage cabinets, all built around high-efficiency MPPT technology and smart monitoring.
