SolaX X3-IES-5K 5kW All-in-One Hybrid Inverter (3-phase)
Code: X3-IES-5K
Related products
Product detailed description
Overview
SolaX X3-IES-5K - 5 kW three-phase all-in-one hybrid inverter (X3-IES) for stackable HV battery storage. IP66, 98.5% efficiency.
Key Features
- 5 kW three-phase all-in-one hybrid inverter (X3-IES)
- Modular: 10-30 kWh stackable battery, 160-800 V
- 200% PV oversizing, 50 A charge/discharge
- EPS off-grid backup; AFCI + DC arc protection
- IP66; max. efficiency 98.5%
Technical Specifications
| System type | All-in-one hybrid inverter (X3-IES) for stackable battery |
| Rated AC output power | 5 kW |
| Max. AC apparent power | 5.5 kVA |
| Rated output current | 7.3 A @ 400 V |
| Phase | Three-phase (3W/N/PE), 230/400 V |
| No. of MPP trackers | 2 |
| Battery type / voltage | Lithium, 160-800 V (HV) |
| Max. charge / discharge current | 50 A |
| EPS (off-grid) output | yes, with battery |
| Max. efficiency | 98.5% |
| Communication | RS485, CAN, USB |
| Protection rating | IP66 |
| Safety | AFCI + DC arc protection |
| Dimensions | to be confirmed |
| Weight | to be confirmed |
| Certifications | EN/IEC 62109, IEC62619 |
Compatible Batteries
Designed for the matching SolaX IES stackable battery modules. Always confirm the exact configuration with the supplier.
Additional parameters
| Category: | Solar inverters |
|---|---|
| Weight: | 35 kg |
| Brand: | SolaX |
| Power: | 5000 W |
| Number of phases: | 3 |
| Degree of protection (IP): | IP66 |
| Number of MPPT: | 2 |
| Type: | Hybrid |
| Nominal voltage: | 400 V |
