SolaX X3-IES-8K 8kW All-in-One Hybrid Inverter (3-phase)

Code: X3-IES-8K

Not rated Rating details

Brand: SolaX Power

€0 €0 incl. VAT

SolaX X3-IES-8K - 8 kW three-phase all-in-one hybrid (X3-IES) for stackable HV battery storage. IP66, 98.5% efficiency.

Detailed information

Fair price

We offer competitive prices with an emphasis on quality and transparency

Fast delivery

Products in stock, ships now. Backordered items ship in 5 days.

Loyalty bonus

Regular customers get discounts and bonuses for their loyalty.

Expert turnkey installation

We provide end-to-end services with a quality guarantee.

Product detailed description

Overview

SolaX X3-IES-8K - 8 kW three-phase all-in-one hybrid inverter (X3-IES) for stackable HV battery storage. IP66, 98.5% efficiency.

Key Features

8 kW three-phase all-in-one hybrid inverter (X3-IES)
Modular: 10-30 kWh stackable battery, 160-800 V
200% PV oversizing, 50 A charge/discharge
EPS off-grid backup; AFCI + DC arc protection
IP66; max. efficiency 98.5%

Technical Specifications

System type	All-in-one hybrid inverter (X3-IES) for stackable battery
Rated AC output power	8 kW
Max. AC apparent power	8.8 kVA
Rated output current	11.6 A @ 400 V
Phase	Three-phase (3W/N/PE), 230/400 V
No. of MPP trackers	2
Battery type / voltage	Lithium, 160-800 V (HV)
Max. charge / discharge current	50 A
EPS (off-grid) output	yes, with battery
Max. efficiency	98.5%
Communication	RS485, CAN, USB
Protection rating	IP66
Safety	AFCI + DC arc protection
Dimensions	to be confirmed
Weight	to be confirmed
Certifications	EN/IEC 62109, IEC62619

Compatible Batteries

Designed for the matching SolaX IES stackable battery modules. Always confirm the exact configuration with the supplier.

Additional parameters

Category:	Solar inverters
Weight:	35 kg
Brand:	SolaX
Power:	8000 W
Number of phases:	3
Degree of protection (IP):	IP66
Number of MPPT:	2
Type:	Hybrid
Nominal voltage:	400 V

SolaX X3-IES Datasheet (PDF)
