SolaX X3-PRO-10K-G2 10kW On-grid Inverter (3-phase)
Code: X3-PRO-10K-G2
Fair price
We offer competitive prices with an emphasis on quality and transparency
Fast delivery
Products in stock, ships now. Backordered items ship in 5 days.
Loyalty bonus
Regular customers get discounts and bonuses for their loyalty.
Expert turnkey installation
We provide end-to-end services with a quality guarantee.
Product detailed description
Overview
SolaX X3-PRO-10K-G2 10kW On-grid Inverter (3-phase) - on-grid (grid-tie) string inverter for solar PV without battery storage.
Key Features
- 10 kW three-phase on-grid string inverter (X3-PRO G2)
- 2 MPP trackers
- IP66
- Residential / small-commercial PV
Technical Specifications
| Rated AC output power | 10 kW |
| Phase | Three-phase (3/N/PE), 230/400 V |
| No. of MPP trackers | 2 |
| Max. PV input voltage | 1000 V |
| Max. efficiency | 98.2% (Euro 97.7%) |
| Protection rating | IP66 |
| Dimensions (W x H x D) | 482 x 417 x 186 mm |
| Weight | 24.5 kg |
Additional parameters
| Category: | Solar inverters |
|---|---|
| Weight: | 24.5 kg |
| Brand: | SolaX |
| Power: | 10000 W |
| Number of phases: | 3 |
| Degree of protection (IP): | IP66 |
| Number of MPPT: | 2 |
| Type: | Grid tie |
| Nominal voltage: | 400 V |
Product rating
Be the first who will post an article to this item!
Only registered users may submit ratings. Please log in or sign up.
Discussion
Be the first who will post an article to this item!
SolaX Power is a leading global manufacturer of solar inverters and energy storage systems for residential, commercial and industrial applications. Its range includes hybrid and on-grid inverters (X1, X3, X3-Ultra, X3-Forth), all-in-one IES systems, Triple Power batteries and C&I storage cabinets, all built around high-efficiency MPPT technology and smart monitoring.
| Manufacturing company : | SolaX Power Network Technology (Zhejiang) Co., Ltd. |
|---|---|
| Address : | No. 288 Shizhu Road, Tonglu Economic Development Zone, Tonglu, Hangzhou, Zhejiang, China |
