Deye BOS-B-PDU-2-A HV Battery Control Box (BMS)
Code: BOS-B-PDU-2-A
Product detailed description
Overview
Deye BOS-B-PDU-2-A - high-voltage battery control box (BMS) for the BOS-B C&I energy storage solution. 200-1000 V, 180 A, with display and Wi-Fi/Bluetooth.
Key Features
- HV battery control box (BMS) for the BOS-B C&I stack
- Operating voltage 200-1000 V, 180 A
- Display + Wi-Fi/Bluetooth + CAN/RS485
- Manages the BOS-B module stack
- Rack-mounted, IP20
Technical Specifications
| Function | HV battery control box (BMS) for BOS-B |
| Operating voltage | 200-1000 Vdc |
| Nominal discharge current | 180 A |
| AC input | 220 V +/-10%, 2 A |
| Communication | CAN / RS485 / Wi-Fi / Bluetooth |
| Display | LCD |
| Protection rating | IP20 |
| Dimensions (W x H x D) | 788.6 x 526 x 167.2 mm |
| Weight | 32 kg |
System Compatibility
Part of the Deye high-voltage energy storage range. Always confirm the exact configuration with the supplier.
Additional parameters
| Category: | Batteries for photovoltaics |
|---|---|
| Weight: | 32 kg |
| Brand: | DEYE |
| Lenght: | 526 mm |
| Width: | 789 mm |
| Height: | 167 mm |
| Degree of protection (IP): | IP20 |
| Communication: | RS485, CAN |
| Operating voltage: | 200-1000 V |
