Deye BOS-B Pro 16.08kWh HV Battery Module (A3)
Code: BOS-B-PACK16-A3
Related products
Product detailed description
Overview
Deye BOS-B Pro 16.08 kWh high-voltage LiFePO4 battery module (51.2 V, 314 Ah) for the BOS-B C&I energy storage solution. Rack-mounted, IP20.
Key Features
- 16.08 kWh HV LiFePO4 battery module (51.2 V, 314 Ah)
- Building block of the Deye BOS-B C&I ESS solution
- 5-16 modules in series per PCS
- 6000 cycles at 90% DoD
- Rack-mounted, IP20
Technical Specifications
| Energy per module | 16.08 kWh |
| Battery chemistry | LiFePO4 (LFP) |
| Nominal voltage | 51.2 V |
| Capacity | 314 Ah |
| Max. charge/discharge current | 180 A |
| Scalability | 5-16 modules in series per PCS |
| Cycle life | 6000 cycles (90% DoD) |
| Protection rating | IP20 |
| Mounting | Rack-mounted |
| Operating temperature | charge 0-55 / discharge -20-55 °C |
| Dimensions (W x H x D) | 795.9 x 526 x 274.2 mm |
| Weight | 123 kg |
| Warranty | 10 years |
System Compatibility
Part of the Deye high-voltage energy storage range. Always confirm the exact configuration with the supplier.
Additional parameters
| Category: | Batteries for photovoltaics |
|---|---|
| Weight: | 123 kg |
| Brand: | DEYE |
| Lenght: | 526 mm |
| Width: | 796 mm |
| Height: | 274 mm |
| Degree of protection (IP): | IP20 |
| Communication: | RS485, CAN |
| Nominal voltage: | 51.2 V |
| Battery type: | High voltage |
| Usable energy: | 16.08 kWh |
