Deye SUN-7K-G02P1-EU-AM2
Code: DEYE-SUN-7K-G02P1-EU-AM2
Product detailed description
Key Features
Remote Shutdown Function / Intelligent Monitoring Platform
Deye inverter products are equipped with an intelligent monitoring platform that supports remote shutdown in case of an accident. This platform also allows remote parameter setting and firmware upgrade, making the operation and maintenance of photovoltaic power plants more convenient and efficient.
High Efficiency: Achieves a maximum efficiency of up to 97.7% with dual MPPT trackers, ensuring maximum energy output from solar panels.
Low Start-up Voltage: Starts at a low voltage of 80V, allowing optimal performance even in low light conditions.
Zero Export Application: Supports zero export function, allowing you to manage energy consumption and maximize self-consumption.
VSG Application: Enables voltage support functions, contributing to grid stability.
Intelligent String Monitoring: Offers optional intelligent string monitoring for advanced system diagnostics.
Wide Output Voltage Range: Provides flexible output voltage to be compatible with various grid configurations.
Anti-PID Function: Optional anti-PID function helps prevent power degradation caused by PID phenomenon in photovoltaic modules.
Comprehensive Protection: Includes DC reverse polarity protection, AC output overcurrent/overvoltage protection, short circuit protection, thermal protection, and overvoltage protection.
Monitoring and Communication: Supports various communication interfaces including GPRS/WIFI/Bluetooth/4G/LAN (optional), RS485/RS232, and monitoring modes.
Additional parameters
| Category: | Inverters |
|---|---|
| Weight: | 12.1 kg |
| Brand: | DEYE |
| Lenght: | 208.5 mm |
| Width: | 330 mm |
| Height: | 310 mm |
| Power: | 7000 W |
| Number of phases: | 1 |
| Degree of protection (IP): | IP65 |
| Communication: | RS485, RS232 |
| Number of MPPT: | 2 |
| String: | 1 + 2 |
| Type: | Network |
| Voltage converters - DEYE - Model series: | G02P1-EU-AM2 | 1 Phase | 2 MPPT |
| Nominal voltage: | 230 V |
| Operating voltage: | 70-500 VDC |
| Maximum Output Power: | 7700 VA |
