Solis-255K-EHV-5G-PLUS
Code: SOLIS-255K-EHV-5G-PLUS
Fair price
We offer competitive prices with an emphasis on quality and transparency
Fast delivery
Products in stock, ships now. Backordered items ship in 5 days.
Loyalty bonus
Regular customers get discounts and bonuses for their loyalty.
Expert turnkey installation
We provide end-to-end services with a quality guarantee.
Product detailed description
Key Features
- > 150% DC/AC ratio
- Night SVG function
- IP66
- 9/12/14 MPPTs, max. efficiency 99.0%
- DC side supports "Y" connector
- High power tracking density 56MPPT/MW
- Compatible with 550W+ bifacial modules
- Fuse free design, safe and maintenance free
- Power line communication (PLC) (optional)
- Intelligent string monitoring, smart I-V curve scan
- Remote firmware upgrade with simple operation
- Built-in PID recovery for better module performance
- Globally recognised branded componentry forlonger life
- Certified by TÜV Rheinland with VDE-AR-N4130, supporting grid connectionsat Extra High Voltages ≥150kV for enhanced grid adaptability
Additional parameters
| Category: | Inverters |
|---|---|
| Weight: | 113 kg |
| Brand: | Solis |
| Power: | 255000 W |
| Number of phases: | 3 |
| Degree of protection (IP): | IP66 |
| Number of MPPT: | 14 |
| Communication: | RS485, PLC |
| Maximum output current: | 552 A |
| Nominal voltage: | 800 V |
| Lenght: | 384 mm |
| Width: | 1125 mm |
| Height: | 770 mm |
| String: | Up to 2 per MPPT |
| Type: | Network |
Be the first who will post an article to this item!
Only registered users may submit ratings. Please log in or sign up.
Be the first who will post an article to this item!
Add a comment
Founded in 2005, Solis stands as one of the largest and most experienced manufacturers of solar inverters worldwide. Offering cost-effective solutions under the Solis brand, the company serves residential, commercial, and utility-scale customers, providing value across the entire solar supply chain. Its innovative string inverter technology ensures high reliability, meeting rigorous international certification standards.
