    Victron MultiPlus-II 48/5000/70-50 GX

    Code: VICTRON-MP-II-48-5000-70-50-GX
    Not rated
    Victron MultiPlus-II 48/5000/70-50 GX
    €910,57 €1 120 incl. VAT
    In external warehouse
    Delivery to:
    25.06.2025

    More than just an inverter/charger, the MultiPlus-II GX is a device with built-in networking capabilities that facilitates communication with solar chargers, batteries and other devices to manage on-grid, off-grid or remote devices. It is versatile, supports parallel operation to increase battery power or charging speed, and can be configured for three-phase power. With a range of advanced features such as uninterruptible power supply, load limit setting and the ability to supplement limited grid power availability with battery power, all controllable directly from your phone or smart device, the MultiPlus-II GX offers comprehensive control. Remote monitoring is also easily achieved.

    Detailed information

    Product detailed description

    Key Features

    • MultiPlus-II with LCD display and GX function
      The MultiPlus-II GX integrates the MultiPlus-II inverter/charger and the GX device with a 2 x 16 character display.
    • Display and Wi-Fi
      The display shows the parameters of the battery, inverter and solar charge controller.
      The same parameters can be accessed using a smartphone or other Wi-Fi enabled device.
    • GX Device
      The integrated GX device includes:
      - BMS-Can interface. This can be used to connect to a compatible battery controlled by CAN bus. Please note that this is not a
      VE.Can compatible port.
      - USB port.
      - Ethernet port.
      - VE.Direct port.
    • Applications
      The MultiPlus-II GX device is intended for applications where additional connectivity to other products and/or remote
      monitoring is required, such as on-grid or off-grid energy storage systems and some mobile applications.
    • Parallel and three-phase operation
      Only one GX unit is required for parallel and three-phase operation.

    Additional parameters

    Category: Inverters
    Weight: 31 kg
    Brand: Victron Energy
    Power: 5000 W
    Number of phases: 1
    Degree of protection (IP): IP22
    Communication: VE.Bus
    Nominal voltage: 230 V
    Lenght: 148 mm
    Width: 323 mm
    Height: 565 mm
    Type: Off-Grid
    Battery Voltage: 48 V
    Rated Battery Charge Current: 70 A
    Transfer switch: 50 A
